Fully Automatic In-Line Turntable Stretch Wrapper with Integrated Top Sheet Dispenser

Supports Customization：Customization for special specifications is supported
Industries Served：Food, Beverages, Chemicals, Paper Manufacturing, and Building Materials.
Product Overview：Fully Automatic In-Line Turntable Stretch Wrapper with Integrated Top-Sheet Unit Dual Operating Modes: Choose between stretch wrapping only or stretch wrapping + top-sheet covering to suit different packaging requirements. Fully Automated Film Handling: Stretch wrapping unit: Automatically feeds, cuts, and applies stretch film. Top-sheet unit: Automatically pulls, cuts, and applies top-cover film. Powered Pre-Stretch Film Carriage with up to 250% pre-stretch ratio, significantly reducing film consumption while enhancing load stability. Intelligent Photoelectric Sensors detect pallet dimensions and automatically execute the complete wrapping and top-sheet sequence. User-Programmable Parameters via HMI/PLC: Number of wrap layers Top/bottom reinforcement wrap cycles Overhead traverse (top-sheet) dwell time Film tension control for optimal load containment Automatic Arm Return-to-Home after each cycle for consistent positioning. High-Sensitivity Emergency Braking System ensures immediate stop on fault or intrusion. Safety Features: Visual flashing warning light during operation Optional protective safety guarding/netting Photoelectric safety sensors at infeed/outfeed zones to prevent accidents during pallet entry/exit

+86 17701725961

Model Specifications

Specification / Parameter	Value
Stretch Film Roll Dimensions	Length: 800–1200 mm × Width: 800–1200 mm
Max. Wrapping Height	2100 mm
Turntable Load Capacity	2500 kg
Packaging Throughput	18–25 pallets/hour
Turntable Speed	0–15 rpm, frequency-controlled (adjustable)
Turntable Height	456 mm
Pneumatic System Operating Pressure	0.4 – 0.7 MPa
Top-Sheet Unit Lifting Speed	3 m/min
Top-Sheet Film Stretching Speed	12 m/min
Top-Sheet Film Coverage Size	Width: 1700 mm, Length: Adjustable
Film Cutting Method	Instantaneous heated wire cut-off
Film Carriage Travel Speed	3 m/min
Control System	PLC-controlled; adjustable wrap layers and cycles; auto turntable return-to-home; auto load height detection
Machine Weight	1800 kg
Power Supply	3-phase, 380 V AC, 50/60 Hz, 20 A, 3 kW

Support & Services

Quality Assurance, Efficient Collaboration

Speed specializes in the R&D of end-of-line automated packaging systems. We hold multiple invention patents in packaging equipment and employ a team of senior electromechanical engineers and designers to ensure product quality and project efficiency.

Dedicated Shipment & Rigorous Testing

We deliver on schedule as agreed. Every machine undergoes strict factory testing before shipment. Equipment is wrapped in stretch film and secured in wooden crates or with wooden bracing for full protection against moisture and damage during transit—shipped as a complete unit.

Premium After-Sales Service

Prior to equipment commissioning, we provide free on-site training for your installation and management teams at the project location. Training covers equipment installation, system components, operation procedures, and maintenance protocols.
